Nitrous oxide induced neuropathy correlated with MRI imaging

INTRODUCTION

Nitrous oxide (N₂O) gas, commonly known as laughing gas, has long been used as an anaesthetic in medical settings [1–3]. However, its use is declining due to its known side effects which include neurotoxicity resulting from reduced vitamin B12 bioavailability in cases of abuse.^1,2 Recently, there has been a reported rise, particularly amongst young people, in the abuse of this substance with the lifetime prevalence in the UK being around 38.6%, being the thirteenth most used recreational drug according to the Global Drug survey of 2021.^4–6 When inhaled, N₂O creates a sense of euphoria, but can also cause dizziness, slurred speech, drowsiness and can even cause loss of consciousness in some cases.^2,7 Although most use the drug infrequently, with little harm ensuing, there appears to a subset of users that use it significantly more often and may develop dependency (5). Symptoms of nitrous oxide abuse have been reported as mainly neurological, with subacute combined spinal cord degeneration, likely linked to the decrease in bioavailable vitamin B12.⁸

CASE REPORT

A twenty-seven-year-old male presented to the emergency department complaining of bilateral paraesthesia in their arms and legs which had been developing over the past two weeks, without any history of recent trauma. The patient's daily treatment was 20mg of methylphenidate and two 500mg pills of diosmin (450mg) and hesperidin (50mg). The neurological exam showed decreased tactile and pain sensitivity in the legs and feet, with the patient being unable to stand. The patient exhibited dysmetria when asked to perform a finger-to-nose test, attributed to a lack of strength. The rest of the physical exam was normal. The physician requested a cervical spine CT-exam to exclude a disc hernia. The patient was then seen by a neurologist, to whom he admitted having heavy recreational use of N₂O, having consumed multiple balloons, filled with N₂O from small canisters, two weeks prior. A blood test was performed, revealing vitamin B12 < 150ng/L, a slightly increased white blood cell count (11 000/mm³), increased fibrinogen (472mg/dl), increased direct bilirubin (0,3 mg/dl) and GPT (44 U/L) and a slightly increased CRP (12.8mg/L) The rest of the blood test was normal. The patient promptly hospitalised and seen by a neurologist, whom, suspecting N₂O toxicity, requested a CSF analysis, an electromyography and an MRI.

The electromyography exam revealed a decreased conduction speed of the left sural nerve. The CFS analysis was normal.

The patient was treated with 1mg of vitamin B12 per day via intramuscular injection (IM) on the 3^rd day after admission. This regiment continued for one week, followed by 1mg IM per week thereafter.

The MRI revealed hyperintense zones in the dorsal column of the cervical spinal cord from C2 to C6 in T2-weighted sequences (Figure 1 and Figure2).

Figure 1

Sagittal T2-weighted image of the cervical spine showing a hyperintense signal from C2 to C6 within the spinal cord (arrows)

Figure 2

Axial T2-weighted image of the cervical spine showing a hyperintense signal (arrows) within the dorsal column of the spinal cord

Further T1-weighted imaging, with and without gadolinium, did not show any anomalies or enhancement (Figure 3 and Figure 4). This exam was deemed compatible with N₂O toxicity.

Figure 3

Sagittal T1-weighted image of the cervical spine showing no hyper or hypointense areas within the spinal cord

Figure 4

Sagittal T1-weighted contrast-enhanced image of the cervical spine showing no zones of focal enhancement

The patient’s clinical evolution was positive; quickly regaining some of his strength. A follow up blood test performed 8 days later showed vitamin B12 levels above the norm due to the treatment. Following this, the patient underwent 2 months of intensive physical therapy as an inpatient. During this time, he regained much of his strength, being able to walk without support between parallel bars, though requiring a walking frame to move around. However, he continued to exhibit limited ataxia and required help to get up if he fell. He was discharged after 2 months d to an outpatient clinic to continue his treatment once he was able to move using a walking frame. After 4 months he regained of the ability to walk at a pace of 5km/h for 20 minutes and use a stationary bicycle for the equivalent distance of 10km. He showed marked strength improvement, however he remained ataxic and had difficulty maintaining balance. At six months the patient continued to have difficulty maintaining balance and had not yet regained the ability to run.

DISCUSSION

Nitrous oxide abuse is a growing problem, with an increased prevalence amongst teenagers and young adults.⁹ The gas is subsequently inhaled from the balloons.⁹ Other methods of administration include direct inhalation from the canister, connecting the canister to a face mask or releasing it into a bag which is then placed over the head of the user.⁹

Nitrous oxide toxicity can result in subacute combined degeneration of the dorsal and lateral spinal columns as well as the spinocerebellar tract.^2,10 The symptoms include paraesthesia, which our patient presented with, and sensory ataxia which can be associated with loss of proprioception.^2,7,10 Symptoms can progress to spasticity, clonus, muscle weakness, paraplegia, and faecal and urinary incontinence.^7,10 Further features of the disease can be peripheral axonal degeneration as well as central nervous symptoms such as Lhermitte phenomenon.^7,10

The MRI features of this condition are T2-signal hyperintensity of the posterior, and sometimes lateral column, of the spinal cord.^8,10 Cases of mild contrast-enhancement of the lesions have also been described.⁸ However, some cases exist where there are no visible MRI abnormalities.⁸

There are many purported mechanisms for the neurotoxicity of N₂O involving the induction of vitamin B12 deficiency, classically defined as a serum level under 200pg/ml.² One theory is the N₂O affects vitamin-B12 by permanently oxidising cobalt ions and making the vitamin non-functional without decreasing the concentration itself.^2,8 Vitamin B12 is an essential co-factor in turning homocysteine into methionine, which is necessary for the methylation of myelin, and methylmalonic acid.^2,8 In this way, N₂O toxicity can result in demyelination.⁸ One should note that due to the method of action of N₂O, vitamin B12 levels may appear normal, which could be due a disruption of vitamin B12 availability at the cellular level.^2,8 For this reason, one should also test homocysteine levels, as these may be elevated in N₂O toxicity and provide an essential clue for the diagnosis.⁸

The treatment of nitrous oxide toxicity is based on reversing the vitamin B12 deficiency, with no consistent treatment regimen being apparent amongst the various case reports.⁸ The prognosis is variable, but seems to depend upon prompt treatment, with intramuscular vitamin B12 seeming to be associated with better outcomes than oral supplementation.⁸ Importantly, this treatment must be accompanied by folate supplementation to avoid the methyl folate trap¹¹. To our knowledge, no guidelines exist for the required length of the treatment.

Conclusion

Nitrous oxide is a commonly used recreational drug which can occasionally present with severe neurological side effects. Patients presenting with bizarre neurological symptoms that are clinically compatible with N₂O toxicity, abuse of the substance should be suspected.

MRI features typically include spinal cord T2 hyperintensities centred on the posterior and lateral columns, though these may be absent in some cases. Patients should undergo a blood test for vitamin B12 levels, which may also be normal, and homocysteine levels, which should be increased in cases of N₂O toxicity.

Once the diagnosis of N₂O toxicity is established, prompt vitamin B12 administration, alongside folate supplementation, is required. However, even with rapid diagnosis and treatment, a positive prognosis for the patient is not guaranteed.

REFERENCES

1. Yuan JL, Wang SK, Jiang T, Hu WL. Nitrous oxide induced subacute combined degeneration with longitudinally extensive myelopathy with inverted V-sign on spinal MRI: A case report and literature review. BMC Neurol 2017;17:1–4.
2. Kingma TJ, Bascoy S, Altaf MD, Surampudy A, Chaudhry B. Subacute Combined Degeneration of the Spinal Cord: A Consequence of Recreational Nitrous Oxide Use. Cureus 2022.
3. Zheng D, Ba F, Bi G, Guo Y, Gao Y, Li W. The sharp rise of neurological disorders associated with recreational nitrous oxide use in China: a single-center experience and a brief review of Chinese literature. J Neurol 2020;267:422–9.
4. Moussa AH, Mohamed W, Zidouh S, Moussa AH, Mohamed W, Zidouh S. From Medical Analgesic to Recreational Use: A Rare Case of Acute Myelitis Caused by Laughing Gas Abuse. Cureus 2023;15.
5. Kaar SJ, Ferris J, Waldron J, Devaney M, Ramsey J, Winstock AR. Up: The rise of nitrous oxide abuse. An international survey of contemporary nitrous oxide use. J Psychopharmacol 2016;30:395–401.
6. Winstock A, Maier L, Zhuparris A, et al. GDS 2021 Global Report. London: 2022.
7. Garakani A, Jaffe RJ, Savla D, et al. Neurologic, psychiatric, and other medical manifestations of nitrous oxide abuse: A systematic review of the case literature. Am J Addict 2016;25:358–69.
8. Einsiedler M, Voulleminot P, Demuth S, et al. A rise in cases of nitrous oxide abuse: neurological complications and biological findings. J Neurol 2022;269:577–82.
9. Van Aerts L, De Morais J, Evans-Brown M, et al. Recreational use of nitrous oxide : a growing concern for Europe. Publications Office of the European Union; 2022.
10. Safari A, Emadi F, Jamali E, Borhani-Haghighi A. Clinical and MRI manifestations of nitrous oxide induced vitamin B12 deficiency: A case report. Iran J Neurol 2013;12:111.
11. Marotta DA, Kesserwani H. Nitrous Oxide Induced Posterior Cord Myelopathy: Beware of the Methyl Folate Trap. Cureus 2020;12.
